GAZELLE ULTIMATE T10

Gazelle Ultimate T10 HMB, an exceptional electric bike designed for the great outdoors, blending sporty performance with award-winning craftsmanship and top-notch finishes.

Key Features:

Large Gear Range: Embark on dynamic and hilly terrains with confidence. The Ultimate T10’s derailleur gears provide a wide range for tackling any gradient, offering efficiency and extending the battery life, ensuring you can explore further on a single charge.

Safe and Controlled Braking: Equipped with indispensable hydraulic disc brakes, the Gazelle Ultimate T10 HMB ensures safe and precise braking in all conditions, whether it's raining or the roads are wet, providing peace of mind for advanced e-bike riders.

Front-Fork Suspension for Comfort: Designed for extended, active trips, the telescopic fork offers 75mm of travel for a more comfortable ride over uneven roads. The high-quality fork neutralizes vibrations, reducing fatigue and stress even during extra-long rides.

Powerful Support: Tackle steep hills and extended touring effortlessly with Bosch’s powerful next-gen Performance Line mid-drive motor, providing smooth support with up to 75 Nm of torque. The high-capacity 625 Wh battery ensures no ride is too far.

Bosch Smart System: Experience everything a cyclist's heart desires with the Bosch Performance Line, delivering smooth and powerful assistance with 75 Nm torque, ideal for demanding cyclists.

Efficient, Integrated Power Source: Bosch’s lithium-ion batteries, known for their advanced technology, guarantee a long life. The integrated 625 Wh battery, secured in the frame with a lock, ensures ample range. The battery is easily removable for convenient recharging anywhere.

Battery Specifications
Maximum Range: 65 miles
Watt Hours: 625 Wh
Capacity: 16.7 Ah
Eco Range: 65 miles
Tour Range: 45 miles
Turbo Range: 30 miles

General
Model: Ultimate
Weight: 50.7 lb
Colors: Champion Red, Dust Light, Ivory
Segment: Electric Bicycles
Sitting Position: Sporty

Frame
Frame Shape: High-step, Low-step
Size: 46, 53, 57
Frame Description: Stable aluminum frame with a sporty geometry. Battery, motor, and cables are seamlessly integrated. High-quality finish with attention to detail.
Frame Material: Aluminum

Fork
Material: Aluminum
Suspension Type: Internal to Headset
Travel Fork: 40 mm

Wheels
Wheel Size: 28″
Rims: Ryde Dutch
Tires: Schwalbe Energizer Plus
Tire Color: Black

Brake & Transmission
Gear Type: Derailleur
Gears: 10
Rear Derailleur: Shimano Deore
Front Chainwheel: 38
Rear Chainwheel: 11-36
Brake Front: Disc brake with hydraulic control
Brake Rear: Disc brake with hydraulic control

Handlebar & Seat
Handlebar Description: Aluminum, slightly curved model
Adjustable Stem: Yes
Grip Type: Ergon GP1-L, ergonomic
Grips: Plastic handlebar grips with ergonomic form for better pressure distribution
Saddle: Selle Royal Loire
Front Light Type: Axa Blue Line 50

Engine
Ebike System: Bosch
Engine Location: Mid-drive motor
Max Speed: Class 1 (20 mph)
Torque: 65
Engine Model: Bosch Performance Line (65 Nm)
Ebike Sensors: Pedal force sensor, rotation sensor, speed sensor

Battery
Type: Li-ion
Position: Integrated into frame
Replaceable: Yes
System: Bosch

Display
Amount of Support Levels: 4
Walk Assist: Yes
Display Model: Bosch Purion LCD

Warranty
Frame: 10 years
Fork: 5 years
Paint: 5 years
Other Parts: 2 years
Battery: 2 years
Motor: 2 years
Display: 2 years

Lock
Description: Ring lock with an option for a plug-in cable for extra theft protection
Safety Level: ART ** certified
Type: AXA Defender

Other
Chaincase Description: Aluminum
Kickstand Type: Drop-down rear stand
Chaincase Type: Chain guard
Rear Carrier Description: Aluminum

Experience the Gazelle Ultimate T10 HMB, where innovation meets adventure.
