SCOTT LUMEN 900 eRIDE 2024

Key Features

• Lumen Carbon HMX Frame
• FOX 34 Float Performance 130mm Fork
• FOX NUDE 6T EVOL, TwinLoc, 130mm
• SRAM GX AXS Transmission 12Sp
• SRAM Level Silver 4 Piston
• Schwalbe Wicked Will Tires

• Frame

  Carbon HMX
  Integrated Suspension Technology
  Flex Pivot / Adjustable head angle
  Syncros Cable Integration System
  TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline

• Travel

  Front: 130mm / Rear: 130mm

• Fork

  FOX 34 Float Performance Elite Air FIT4
  3 modes with low Speed adj. / Kabolt 15x110mm axle
  44mm offset / tapered steerer / Reb. Adj. / Lockout
  130mm travel

• Rear Shock

  FOX NUDE 6T EVOL Trunnion
  SCOTT custom w. travel / geo adj.
  3 modes: Lockout-Traction Control-Descend
  Low Speed Adj. / Custom large Air volume / Reb. Adj.
  Bearing Hardware / Travel 130-90-Lockout / T165X45mm

• Remote System

  SCOTT TwinLoc 2 Technology
  Suspension & Dropper Remote
  3 Suspension modes

• Drive Unit

  TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph

• Battery

  TQ Internal 360Wh

• Display

  TQ HPR
  Bluetooth / ANT+ / Dedicated Smartphone app

• Charger

  TQ 100-240V-4A

• Rear Derailleur

  SRAM GX Eagle AXS Transmission 12 Speed
  Wireless Electronic Shift System

• Shifters

  SRAM GX Eagle AXS Rocker Controller

• Crankset

  FSA Carbon crankset / 175mm / 34T

• Chainguide

  e*thirteen / e*spec Slider

• Chainring

  Scott custom spider / SRAM Eagle Transmission 34T chainring

• Chain

  SRAM CN GX Eagle Transmission

• Cassette

  SRAM GX Eagle XS 1275 Transmission 10-52

• Brakes

  SRAM Level Silver Stealth 4-Piston Disc

• Rotor

  SRAM HS2 CL Rotors / F&R 180mm

• Handlebar

  Syncros Fraser iC SL DC Carbon
  0° rise / back sweep 8° / mini Rise / 760mm
  Syncros Performance XC lock-on grips

• Seatpost

  FOX Transfer Dropper Post
  31.6mm / S size 125mm / M size 140mm
  L size 150mm / XL size 175mm

• Seat

  Syncros Tofino 1.5 Regular
  Titanium rails

• Headset

  Syncros - Acros Angle adjust & Cable Routing HS System
  Stainless
  +-0.6° head angle adjustment
  ZS56/28.6 – ZS56/40 MTB

• Wheelset

  Syncros Silverton 1.5-30 CL
  F: 15x110mm
  R: 12x148mm
  30mm Tubeless ready rim 28H / XD Driver
  Syncros Axle w/Removable Lever
  with 6mm Allen
  T30 and T25 Tools

• Front Tire

  Schwalbe Wicked Will 29x2.4" EVO
  Super Race / TLE / 67EPI / Addix Speed Soft

• Rear Tire

  Schwalbe Wicked Will 29x2.4" EVO
  Super Race / TLE / 67EPI / Addix Speed Grip

• Extras

  SRAM AXS Powerpack
  Syncros Fork Fender

• Accessories

  Syncros Eco Sealant
  Transport Axle

• Approx weight in KG

  16.6 (with tubes)

• Approx weight in LBS

  36.6 (with tubes)

• Max. System Weight

  128kg
  The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
